LX Gas-Fired Steam Boilers

Meet the low NOx Industrial Boiler that will meet your company's efficiency and sustainability goals.

Miura’s low NOx LX Series steam boiler is the high-efficiency, easy-to-use boiler your facility has been dreaming of. The unique design of the LX ensure safety, reliability and efficiency that go unmatched in the industry. The LX can reach NOx regulations as low as 9ppm NOx at 3% corrected O2. While standard firetube boilers require hours to heat up, Miura’s LX Series boilers produce fast steam in less than 5 minutes from a cold start-up. Plus, due to their compact design you can double your steam capacity in the same space or reduce space requirements by half for new construction.

Meet the low NOx Industrial Boiler that will meet your company's efficiency and sustainability goals.
Features

The Miura LX Series industrial Steam Boiler design consists of rows of vertical tubes sandwiched between two rectangular headers. Both headers are encased in a castable refractory with only the tubes exposed to flame and/or combustion gases. The upper header is attached to the lower header only by the tubes. As the tubes expand and contract, the headers float up and down accordingly. This ’floating header’ concept greatly reduces stress and allows for the use of cold feedwater without the fear of significant thermal shock. The ’leaky tube’ problems associated with firetube and bent watertube designs do not exist with Miura LX steam boilers.

  • Gas-fired: Natural Gas or Propane, or both on most models
  • High-efficiency Design
  • High and low-pressure steam options available (300 MAWP, 170 MAWP or 15 MAWP)
  • Low NOx Rating as low as: 9ppm depending on model
  • From cold start to full steam in less than 5 minutes
  • Small footprint; Occupies 50% less floor space than typical firetube boilers
  • Equipped with intelligent BL controller for easy-to-use interface
Features

Contact a Miura Rep

Learn More About LX Boilers

Standard Pressure


Utilization Horsepower
Maximum Pressure [1]
Equivalent Output [2]
Heat Output
Efficiency (fuel to stream) [3]
Operational Weight
Operational Water Content
Shipping Weight
Width
Length
Height
Power Supply
Fuel Type [4]
No. 2 Oil
Gas Supply Pressure
Chimney Diameter (ID)
UNIT

BHP
PSIG
LB/HR
BTU/HR

LBS

LBS
IN.
IN.
IN.


GAL/HR
PSIG
IN.
LX-50-12

50
170
1,725
1.674
85%
4,600
45
4,200
33 7/8"
96 7/8"
101 5/8"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
12" OD
LX-100-12

100
170
3,450
3.348
85%
6,600
60
6,000
33 7/8"
125 1/8"
110 3/4"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
12" OD
LX-150-07

150
170
5,175
5.002
85%
8,800
95
8,000
33 7/8"
138 3/4"
125 5/8"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
LX-200-07

200
170
6,900
6,695
85%
8,800
95
8,000
33 7/8"
138 3/4"
125 5/8"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
LX-250-16

250
170
8,625
8.369
85%
12,700
135
11,500
63"
157 7/8"
127"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
LX-300-16

300
170
10,350
10.043
87%
12,600
130
11,500
63"
157 7/8"
127"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
Note 1: Available 49 and 199 BHP rating for L.A. area.
Note 2: Equivalent output calculated from and at 212ºF (100ºC) feed water at 212ºF (100ºC) steam.
Note 3: Thermal efficiencies are based on high heating values of fuels at 68ºF (20ºC) feed water.
Note 4: UL and c-UL approved for natural gas or propane.
High Pressure


Utilization Horsepower
Maximum Pressure [1]
Equivalent Output [2]
Heat Output
Efficiency (fuel to stream) [3]
Operational Weight
Operational Water Content
Shipping Weight
Width
Length
Height
Power Supply
Fuel Type [4]
No. 2 Oil
Gas Supply Pressure
Chimney Diameter (ID)
UNIT

BHP
PSIG
LB/HR
BTU/HR

LBS

LBS
IN.
IN.
IN.


GAL/HR
PSIG
IN.
LXH-200-07

200
300
6,900
6.695
84%
9,100
100
8,200
33 7/8"
155 5/8"
125 3/8"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
LXH-250-16

250
300
8,625
8.369
86%
13,000
140
11,800
63"
156 1/4"
127"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
LXH-300-16

300
300
10,350
10.043
86%
13,000
140
11,800
63"
156 1/4"
127"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG /LPG
3-5 PSIG
20" OD
Note 1: Available 49 and 199 BHP rating for L.A. area.
Note 2: Equivalent output calculated from and at 212ºF (100ºC) feed water at 212ºF (100ºC) steam.
Note 3: Thermal efficiencies are based on high heating values of fuels at 68ºF (20ºC) feed water.
Note 4: UL and c-UL approved for natural gas or propane.
Low Pressure


Utilization Horsepower
Maximum Pressure [1]
Equivalent Output [2]
Heat Output
Efficiency (fuel to stream) [3]
Operational Weight
Operational Water Content
Shipping Weight
Width
Length
Height
Power Supply
Fuel Type [4]
No. 2 Oil
Gas Supply Pressure
Chimney Diameter (ID)
UNIT

BHP
PSIG
LB/HR
BTU/HR

LBS

LBS
IN.
IN.
IN.


GAL/HR
PSIG
IN.
LXL-50-07

50
15
1,725
1.674
85%
5,100
40
4,700
43 3/8"
118 3/4"
146 5/8"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
12" OD
LXL-100-07

100
15
3,450
3.348
85%
7,500
55
7,000
49 3/8"
154 3/4"
160 1/4"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
12" OD
LXL-150-12

150
15
5,175
5.022
85%
9,700
95
8,900
49 5/16"
137 7/8"
190 1/8"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
LXL-200-12

200
15
6,900
6.695
85%
9,700
95
8,900
49 5/16"
137 7/8"
190 7/8"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
Note 1: Available 49 and 199 BHP rating for L.A. area.
Note 2: Equivalent output calculated from and at 212ºF (100ºC) feed water at 212ºF (100ºC) steam.
Note 3: Thermal efficiencies are based on high heating values of fuels at 68ºF (20ºC) feed water.
Note 4: UL and c-UL approved for natural gas or propane.
Ultra Low Nox


Utilization Horsepower
Maximum Pressure [1]
Equivalent Output [2]
Heat Output
Efficiency (fuel to stream) [3]
Operational Weight
Operational Water Content
Shipping Weight
Width
Length
Height
Power Supply
Fuel Type [4]
No. 2 Oil
Gas Supply Pressure
Chimney Diameter (ID)
UNIT

BHP
PSIG
LB/HR
BTU/HR

LBS

LBS
IN.
IN.
IN.


GAL/HR
PSIG
IN.
LX-100SGN-12

100
170
3,450
3.348
85%
6,600
60
6,000
33 7/8"
140 5/8"
110 3/4"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
12" OD
LX-150SGN-07

150
170
5,175
5.022
85%
8,800
95
8,000
33 7/8"
154 3/4"
125 5/8"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
LX-200SGN-07

180
170
6,210
6.026
85%
8,800
95
8,000
33 7/8"
154 3/4"
125 5/8"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
LX-250SGN-16

250
170
8,625
8.369
87%
12,700
135
11500
63"
157 7/8"
127"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
LX-300SGN-16

300
170
10,350
10.043
87%
12,600
130
11,500
63"
157 7/8"
127"
575,460,380,230, or 208V, 3 Phase, 60Hz
NG / LPG
3-5 PSIG
20" OD
Note 1: Available 49 and 199 BHP rating for L.A. area.
Note 2: Equivalent output calculated from and at 212ºF (100ºC) feed water at 212ºF (100ºC) steam.
Note 3: Thermal efficiencies are based on high heating values of fuels at 68ºF (20ºC) feed water.
Note 4: UL and c-UL approved for natural gas or propane.
